Stainless steel 1.25 mm or 1.5 mm; 1.4301/304
other materials on request
IP 66 according to EN 60529
High pressure cleaner resistant (IP69K) on request
09 according to IEC 62262
HL 3 gemäss DIN EN 45545
HL 3 gemäss DIN EN 45545
HL 3 gemäss DIN EN 45545
HL 3 gemäss DIN EN 45545
-40° C to +80° C
Other temperature application ranges on request
ground, grain 240
other surface on request
Bottom part of housing with screw-on webs and threaded holes for mounting rail support, 4 bottom stampings with fastening openings and sealing plugs.
Alternative: Without mounting holes, cover with threaded bolts inside and captive cover screws.
We machine the enclosures according to your drawing. You bear no risk of rejects and you benefit from cost-effective production, fast delivery times and consistent quality, starting with a minimum quantity of 1 piece.
Learn more
If our standard painting does not correspond to your idea or your company design, we also paint the enclosures in your desired color. Just let us know the desired RAL color, structure and gloss level.
Learn more
If you would like to have your company logo or inscription on the enclosure, this is no problem. We can print the enclosures for you using pad printing or screen printing processes. For motifs with detailed color gradient we use digital printing on a front foil.
Learn more
Do you need case labeling for harsh environments? Then engraving or laser marking is just the right thing. The engraving can be covered with color afterwards.
Learn more
As a full-range supplier of terminal boxes, it is part of our standard to also procure components that we assemble for you. Send us a parts list for this purpose and you will receive a ready-assembled enclosure.
Our assembly is set up to deliver the terminal boxes to you fully assembled. Terminal blocks and cable glands of common manufacturers are available from stock. However, we will procure any desired component to provide you with an uncomplicated full service.
Learn more
Tell us how you want your enclosures packaged. Bulk packed for quick further processing at your site or individually packed in protective foil or customer final packaging. We also offer the option of labeling with your part number or serial number.
Contact us if you are intested in our stainless steel enclosures, junction boxes and solutions. We happily present to you our services.
